Rated Current: 2A–25A

Rated Voltage: 125/250V AC, 50V DC

Short-Circuit Test: 250V AC, 1000A

Dielectric Withstand Voltage: 1500V AC for 1 minute

Overload Capacity: 10 times rated current

Voltage Drop: Less than 0.25V

Insulation Resistance: Greater than 500 MΩ

Terminal Temperature Rise: <65 K at 100% rated current, stabilized at 25 °C

Reset Time: Resets within 60 seconds

Reset Mode: Manual reset

Test Standards (Constant Temperature 25 °C)

    100% Current Test: No trip

    150% Current Test: Trips within 1 hour

    200% Current Test: 4–40 seconds to trip

    300% Current Test: 1.2–15 seconds to trip
